    Vaisala 143 Dewpoint Analyzer Micro Moisture Meter Measurement Instrument PP20 Conversion [KST-VII]

    Dew Point Micro Moisture Meter | Vaisala 143 KST-VII with Resistance Capacitance PP20 Conversion

    Product Overview

    This high-precision dew point meter features an integrated Vaisala 143 capacitance-resistance sensor, delivering laboratory-grade accuracy and rapid measurement response. Engineered for trace moisture analysis, it supports real-time display of dew point (-8 to +20°C Td), PP20, PPMV, temperature, and flow rate via an 800×480 HD touch screen. The self-locking quick connector enables plug-and-play field operation, while a lithium battery provides >8 hours of continuous use for outdoor applications. Compliant with DL/T1366-2023 standards, it is ideal for moisture detection in compressed air, SF6, N2, and H2 gases across power systems.
    Key Advantages
    1. Self-Calibration System:Maintains accuracy without external calibration tools.
    2. Dynamic Measurement Tracking:Real-time curve display for moisture trend analysis.
    3. Dual-Power Redundancy:Lithium battery with AC/DC backup for uninterrupted field use.
    4. Comprehensive Data Management:USB export, thermal silent printing, and large-capacity storage.
    5. Intelligent Probe Protection:Automatic self-diagnosis to extend sensor lifespan.

    Technical Parameters

    CategoryDetails
    Dew Point Range-8 to +20°C Td
    Humidity Range0–100%
    Temperature Range-40 to +80°C
    Dew Point Accuracy±0.5°C Td (benchmarked)
    Resolution0.1°C Td
    Response Time-60→20°C Td: 5s [30s]; 20→-60°C Td: 10s [300s]
    Working Temperature-20 to +50°C
    Flow Rate0.5–0.6 L/min
    Measured GasesAir, N2, SF6
    Power SupplyAC220V / Lithium battery (>8-hour runtime)
    Display800×480 touch screen (dew point, PPMV, PP20, flow, temperature)
    Dimensions414×333×177mm
